Measuring systems for stationary and mobile use

Roughness measuring systems from ACCRETECH

Roughness measuring instruments

Measuring systems and tester for quality room and manufacturing

Surface roughness is a measurement of the structure of a surface. It is calculated as a vertical deviation of the actual surface from its ideal shape and form, caused by machining or by chemical or physical processing in production. If these deviations are high, the surface is rough. If the value is low, the surface is smooth. Surfaces vary from part to part which is why the selection of the most fitting surface roughness measurement solution is essential.

The ACCRETECH roughness measuring systems

Link to: HANDYSURF+ 35/40/45

Portable, user-friendly and versatile surface measuring gauge

  • 2.4″ LCD colour display
  • High resolution of 0.0007 µm
  • Probe heads easy to change for different applications

more info

Link to: SURFCOM TOUCH 35/40/45

Mobile surface measuring systems with skid attachment for production and measuring room

  • Excellent price-performance ratio
  • 7.0″ touch display
  • Depending on the application, probe arms can be combined with the evaluation unit

more info


Mobile surface measuring system with free probe system, high straightness precision and large measuring range

  • Resolution of up to 0.0001 µm
  • X axis guide accuracy of 0.3 µm
  • Easy probe arm change and calibration

more info

Link to: SURFCOM TOUCH 550

High-precision roughness measuring instrument for the measuring room, with automatically controlled Z and X travel axis

  • Resolution up to 0.0001 μm and maximum Z measuring range of 1000 μm
  • X axis guide accuracy of 0.2 µm
  • User-friendly analysis unit with touch display

more info

Link to: SURFCOM NEX 001

Roughness measuring instrument with patented linear system for highly precise measurements with high measuring speed

  • High resolution of the measurement probe up to 0.0001 µm
  • Straightness precision: (0.05 µm +1L/1000)
  • Measurement is possible in the X and Y direction
  • Can be extended with 2D and 3D surface measurement

more info

Link to: SURFCOM C5

Fully automated CNC roughness measurements on motor components and shafts

  • Designed for quality assurance for final inspections in series production
  • 5 CNC axis
  • Measurement in all directions with swivelling probe head
  • Active vibration table minimises environmental influences

more info

Applications in medical, aerospace, mechanical engineering and automotive

The roughness of surfaces determines their quality to a large extent. In medical technology, for example, micro-morphological processing on dental implant surfaces creates roughness that ensures optimal stability of the implant after it has been set as well as after the healing period. This means that keeping a certain level of surface roughness in the mid range will help the implant to take root in the jaw quickly and without complications. This also applies to other endoprostheses such as hip joints. In this case, high surface roughness ensures that the implant and the bones bond well.

The form and surface roughness are designed deliberately to achieve optimal surgery successes and ingrowth. With adequate test equipment, the quality of those implants can be increased.

In other industries, too, roughness is a central parameter for surface quality: In mechanical engineering, for example, pre-treating steel surfaces can significantly improve the roughness profile and thus the contact ratio and adhesion of the subsequent coating. In the case of work-pieces with pre-coating, the quality requirements of the surface roughness differ and need test equipment. With profile measuring equipment relevant criteria can be collected. R-parameters for example are usually evaluated along the sampling length.

Low surface roughness on honed cylinder bores in the drive train of combustion engines, for instance, provides frictional optimisation of cylinder running surfaces – and thus generates higher performance, quieter operation and longer lifespan for car engines. To achieve safety, longevity and quality, those cylinder bores require a good profile characterization and the perfect form.

Measure surface roughness according to all important standards

Many parameters can be used to describe the texture of surfaces and profiles. The peak/valley parameters most often used, such as Ra, Rz or curve parameters such as RMR are described in the norms DIN EN ISO 4287/4288 and DIN EN ISO 13565-1/2 for physical metrology. DIN EN ISO 3274 describes the parameters and operators regarding their definition for optical 3D surface measurement. If the sampling length for example is not given, the ISO norms help to define the calculations.

With the ACCRETECH gauging systems for roughness, deviations from the target surface texture can be detected with nanometre-precise certainty – in both manufacturing and in the measuring room. Tactile measurement and the stylus tip have hereby contact to the workpiece and is able to measure in nanometre range.

The roughness measuring systems from ACCRETECH – whether optical or contact – measure in compliance with these DIN norms. They also support international norms such as the American Society of Mechanical Engineers (ASME), Japan Industrial Standards (JIS) and the French CNOMO norm. Gauging systems for 2D and 3D roughness measurements are available as well. All take fully automated measurements; this makes the software for operation self-explanatory to a large extent.

ACCRETECH provides roughness measuring instruments for a wide variety of requirements and in various designs: The convenient mobile gauge in the HANDYSURF+ series form the entry level, followed by portable models 35, 40, 45 and 50 from the SURFCOM TOUCH series for higher requirements. In addition, there are three stationary roughness measuring systems (the SURFCOM TOUCH 550, the SURFCOM C5 and the SURFCOM NEX 001) for use in manufacturing environments or in the measuring room.

Due to the elimination of the drive shaft and the drive gears in the feed, the inspection gauges from ACCRETECH work at a low vibration with a resolution of up to 0.31 nm. Another major advantage of the linear technology, which requires little servicing and maintenance, is the durability of the system and therefore the extraordinary cost efficiency.
